Inquiry
Description
Model
Technical parameters
Certification
Remark
Other models also available, please contact us for details.
DC/DC passive isolator
WAS5 CCC LP 0-20/0-20mA
Input Signal:0…20mA(4…20mA) ; max. input voltage: 18V; max. input current50mA; switching freq.:170KHZ;
CE,UL,CSA
Other models also available, please contact us for details.
DC/DC 2-way isolator
WAS4 VCC DC 0-10/4-20MA
Input:0…10V; max. input voltage:15V; switching freq.:≥13HZ
CE,UL,CSA
Other models also available, please contact us for details.
DC/DC 3-way isolator
WAS5 VCC 0-10V/0-20MA
Input Signal:0…10V;Input max. current/voltage:15V; output signal:0…20 mA; switching freq.:10HZ
CE,cSUus
Other models also available, please contact us for details.
DC/DC 3-way isolator
WAS5 CCC HF 4-20/0-20MA
Input:4…20mA; max. input current:50 mA; output:0…20 mA; switching freq.:≥15KHZ;
CE,UL,CSA
Other models also available, please contact us for details.
Signal distributor
WAS5 CCC 2OLP
Inputcurrent:4…20 mA; outputcurrent(channel): 4…20 mA(current loop); outputcurrent(Channel 2): 4…20 mA(current loop); min. supply voltage:12VDC;switching freq.:30HZ;
CE,cSUus
Other models also available, please contact us for details.
DC/DC 3-way isolator
WAS4 PRO DC/DC
440 Input, output combinations; DIP switching set up; 3-way isolation; Auxiliary Power 20~230VAC/DC; Low Power lose; switching freq. adjustable; Input (adjustable) 20Mv…200V;
CE,cSUus
Other models also available, please contact us for details.
decipak Input Loop Powered Isolator
deciPak Input Loop Powered Isolator
Input range: Direct current 4…20 mA; Max. Input: current30 mA ; Voltage 50V DC; output range: current 4…20 mA;
EN 50081-1,EN 50082-1/EN 61010-1
Other models also available, please contact us for details.
RTD, signal isolator/converter
WAS5 PRO RTD
Input(adjustable):PT100/2-/3-/4-conductor;-200。C~850℃;Ni100:-60℃ ~250。C; Voltage: 0…10V;current:0/4…20 mA;
CE,cSUus
Other models also available, please contact us for details.
PT100, 2-/3-conductor converter
MAS PT100 0…100 ℃
Input sensor PT100/2-/3-conductor,Input temp. range:0…100 ℃; output signal:0…10v/0…5v/0(4)…20mA
CE,cSUus
Other models also available, please contact us for details.
PRO THermo
WAS5 PRO Thermo
Input(adjustable): Thermal converter type EN 60584-1;type K,J,E,N,R,S,B;voltage: 0…10V;current : 0/4…20 mA;
CE,cSUus
Other models also available, please contact us for details.
f/DC isolator/converter
WAS4 PRO Freq
"Input(adjustable);2-, 3-wire PNP/NPN, namur initiator, push-pull step; Threshold / Hysteresis: Namur: approx. 1.7 mA/approx. 0.2
CE,cSUus
Other models also available, please contact us for details.
Universal transducer ITX plus
ITX+ 4-20mA/4-20mA
Input type: Thermocouple, RTD, MA signal, Voltage signal, Millivolt signal, Resistance; Operating voltage: 10-50VDC; output type:4-20 mA (limited at )22 mA;
CE,cSUus
Other models also available, please contact us for details.
PT100, 4-conductor converter
WTS4 PT100/4 V 0-10V
Input:PT100/4-conductor; Temp. range:-200…+800℃ ;Inputcurrent:1.45 mA; output: 0….10V
CE,UL,CSA
Other models also available, please contact us for details.
WAS2 CMR and WAZ2 CMRcurrent Relay output
WAS2 CMR 20/40/60A ac
Inputcurrent:20A ac/40A ac/60A AC; Input freq.: 50HZ/60HZ; 1 changeover contact; Continuous current (AC):3A; Continuous current (DC):0.7A;
CE,cSUus
Other models also available, please contact us for details.
PT100, 3-conductor converter
WTS4 PT100/3 C 0/4-20mA
Input:PT100/3-conductor; Temp. range:-200…+800℃ ; Input current: 1.45 mA; output: 0(4)…20 mA;
CE,UL,CSA
Other models also available, please contact us for details.
Analogue output
WAS2 VMA V ac
Input voltage/ Input impedance: Contact 1: 0V GND; Contact 2: 0…30Vac/30kΩ; Conatct 3: 0…70Vac/70 kΩ; Contact 4:0…130Vac/130 kΩ; Contact 5: 0…250Vac/250kΩ; Contact 6: 0…450Vac/450 kΩ;current/ voltage output(DIP switching) : 0…10V;0…20 mA;4…20 mA; output voltage: 0…10V;
CE,cSUus
Other models also available, please contact us for details.
DC/DC 3-way isolator
MAS DC/DC select
Input Signal:0…10V/0(4)…20 mA; output signal: 0…10V/0(4)…20 mA; switching freq.:>100HZ;
CE,cSUus
Other models also available, please contact us for details.
Input current loop feed
MCZ CCC 0-20mA/0-20mA
Input Signal:0(4)…20 mA; output signal: 0(4)…20 mA;switching freq.:200KHZ
CSA/UL/UR/CE/ESD
Other models also available, please contact us for details.
decipak Input Loop Powered Isolator
deciPak Loop Powered Isolator 0-10mV
Input range: current,voltage singal; Input max. current :100 mA or 1W; output range: 4~20 mA;
EN 50081-1,EN 50082-1/EN 61010-1
Other models also available, please contact us for details.
