Inquiry Photo Description Model Technical parameters Certification Remark


Other models also available, please contact us for details.


Other models also available, please contact us for details.
ZDU2.5 ZDU2.5
Rated Voltage 800V;Rated Current:24A

Rated connection conductor cross-section :(solid) 0.5mm2…4mm2;(flexible): 0.5…4mm2, (flexible plus plastic collar DIN 46228/1)0.5…2.5 mm2;Flammability class UL 94

IEC 60947-7-1/KEMA 97ATEX2521 U Other models also available, please contact us for details.
Terminals ZSI 2.5
rated voltage between adjacent terminals 500V; rated current 6.3A

Rated connection conductor cross-section :(solid) 0.5mm2…4mm2;(flexible): 0.5…4mm2, (flexible plus plastic collar DIN 46228/1)0.5…2.5 mm2;Flammability class UL 94
IEC 60947-7-3/VDE 0611-6 Other models also available, please contact us for details.
Terminals ZTR2.5
Rated Voltage 500V;Rated Current:20A

Rated connection conductor cross-section :(solid) 0.5mm2…4mm2;(flexible): 0.5…4mm2, (flexible plus plastic collar DIN 46228/1)0.5…2.5 mm2;Flammability class UL 94
IEC 60947-7-1/VDE 0100-537 Other models also available, please contact us for details.
Terminals ZDK2.5
Rated Voltage 500V;Rated Current:20A

Rated connection conductor cross-section :(solid) 0.5mm2…2.5mm2;(flexible): 0.5…2.5mm2, (flexible plus plastic collar DIN 46228/1)0.5…2.5 mm2;Flammability class UL 94
IEC 60947-7-1/KEMA 97ATEX4677 U Other models also available, please contact us for details.
ZPE2.5 ZPE2.5
Rated voltage between adjacent terminals 500V; rated impulse voltage between adjacent terminals:6KV

Rated connection conductor cross-section :(solid) 0.5mm2…1.5mm2;(flexible): 0.5…1.5mm2, (flexible plus plastic collar DIN 46228/1)0.5…1.5 mm2;Flammability class UL 94
IEC 60947-7-2/KEMA 01ATEX2106 U Other models also available, please contact us for details.
附件,ZQV2.5/3 ZQV2.5/3
Rated Current: 24A

Other models also available, please contact us for details.
